Marine battery switch, battery isolation switch, yacht battery power-off switch, high current knob switch, battery selector switch
Voltage：50 V
Amps：275 A
Max Amps：1250 A
Position：2
Protect your RV by installing this SEAFLO Battery Master Switch. Rated at 275A continuous, 450A intermittent, 1250A cranking and 50V. Can be recessed or surface mounted.
MORE FEATURES & BENEFITS
• An interchangeable labeling system allowing a full range of applications
• Removable side plates on 4 sides for access of up to 1/0 cables plus a rear cover insulating the rear terminals against any short circuits
• ABS Anti-aging, Anti-ultraviolet
• May be connected to either the positive or the negative electric cable
STANDARD CONFIGURATIONS
| Model | Max. Volt | Amp Draw | Max Amp Draw | Switch Position |
| SFCBS-275-201 | 50 V | 275 A | 1250 A | 2 |
SHIPPING INFORMATION
Unit Weight | 0.46 lbs (0.21 kg) |
Selling Unit Size (L x W x H) | 3.07" x 3.07" x 3.15" (7.8 x 7.8 x 8 cm) |
Selling Unit Weight | 1.21 lbs (0.55 kg) |
Master Carton Size (L x W x H) | 16.26" x 10" x 7.6" |
Master Carton Qty | 30 pcs |
Master Carton Weight | 20.83 lbs (9.45 kg) |
Master Carton Volume | 0.020 m³ |
